1. Input Characteristics:
1.1 InputVoltage Range: 200~240Vac.
1.2 Normal Voltage Range: 220/230Vac.
1.3 Input Frequency Range: 50-60 Hz.
1.4 Max Input AC current: 10A MAX. @ 230Vac.
1.5 Inrush Current: No hazards shall occur orcomponents damage.
1.6 Efficiency: ≥87%@230Vac 60Hz, load follow “2.2 DC output current table” Load 5.
1.7 Active PFC
2. Output Characteristics
2.1 Static Output Characteristics:
Output | Load Range | Regulation | Ripple & Noise | ||
Voltage | MIN. | MAX. | Peak | ||
+5V | 0 A | 12A | -5%/+5% | 150mV | |
+12V | 0A | 130A | -5%/+5% | 200 mV | |
-12V | 0A | 0.3A | -10%/+10% | 200 mV | |
+5VSB | 0 A | 2.5A | -5%/+5% | 150 mV | |
+3.3V | 0A | 12A | -5%/+5% | 150 mV | |
Max. Output Power: 1650W
2.2 DC output current:
Load | +5V(A) | +12V1(A) | +12V2(A) | +3.3V(A) | -12V(A) | +5VSB(A) |
1 | -- | 0.0 | ||||
2 | -- | 1.0 | ||||
3 | -- | 2.0 | ||||
128.0 | 12.0 | 0.30 | 2.0 | |||
5 | 6.0 | 64.0 | 6.0 | 0.15 | 1.0 | |
6 | 2.4 | 25.6 | 2.4 | 0.06 | 0.40 | |
7 | 1.0 | 120.0 | 12.0 | 0.3 | 1.0 | |
8 | 12.0 | 95.0 | 12.0 | 0.3 | 1.0 | |
9 | 0 | 120.0 | 1.4 | 0.3 | 1 | |
10 | 0.90 | 58.0 | 0 | 0.3 | 1 | |
11 | 11.80 | 125.0 | 1.0 | 0.3 | 2.5 | |
120.0 | 12.0 | 0.3 | 2.5 | |||
13 | 0 | 0 | 7.88 | 0 | 0 | |
14 | 0.2 | 0.05 | 0.3 | 0.0 | 0.0 | |
Note: 1. Noise Test: NoiseBandwidth is From 10Hz To 20 MHz.
2. Add 0.1uf Ceramic Capacitor /10uf Tantalum Capacitor At OutputConnector Terminals For Ripple & Noise Measurements.
3. Maximum Continuous DCOutput Power shall not exceed 1650W.
4. +3.3V and +5V total O/P power cannot exceed 100W.
The +12Vcombine is not exceed the 130A
5. Main O/P Shall Be Enabled By Pulled "Remote" Pin To TTLLow Level, And Disabled By
Pulled"Remote" Pin To TTL High Level.
6. When AC line power is applied, the +5VSB will present, and PS-ON signal is in a disable state, the +5VSb o/p shall be within regulation speclimit.
7. Cross regulations/Ripple&Noise test must with Fan cooling and following the defined loads
2.3Dynamic Output Characteristics
2.3.1Turn-On Delay Time: 500mS Max. At Any Condition. Ac Input With Respect To +5V.
2.3.2 Rise Time: any outputs rise time from 10% to 90% of normalvoltage should be less than 20 ms.
2.3.3 Hold-up time: 8ms min.@ 90% of full load 230Vac/60Hz respect to +5V o/p.
2.3.4 Overshoot: Any Overshoot At Turn On Or Turn Off Shall BeLess Than 10% Of The Normal Value.
2.3.5 The power supply should be able topower up and operate normally with the following capacitances simultaneously present onthe DC outputs. This capacitive loading should be used to check stability and should not be included fornoise testing the dynamic timing is 50Hz-10kHz
Note: When dynamic test, the 12V Min Load shall be 2A.
Output Capacitive Loads:
Output | Capacitive Loads(μF) | Max. Step size |
+12VDC | 10000 | 40% |
+5VDC | 6000 | 30% |
+3.3VDC | 6000 | 30% |
-12VDC | 350 | 0.1A |
+5VSB | 350 | 0.1A |
3. Protections:
3.1 OverVoltage Protection: +5V: 7.0V Maximum.
+12V: 16.5V Maximum
+3.3V: 4.3V Maximum
3.2 ShortCircuit Protection: The power supply shall shut down and latch off forshorting. +5V, +12V, -12V or +3.3v rails to com and each output rail andshorting +5vsb P/S can latch down or automatically Recovery When the faultcondition is removed.
3.4 NoLoad operation: No damage or hazardous condition will occur.
3.5 OCP: +12V without,+3.3V&+5Vwith
3.6 With FanSpeed Control Function:
4. Dielectric Withstand Voltage:
4.1 (a) Primary To Secondary: 2100Vac 1sec.
(b) Primary To F.G:2100Vac 1sec.
4.2 Insulation Resistance:Primary To Safety Ground: 500Vdc, 5 MΩ Min.
4.3 Leakage Current: Measured At 240Vac/50Hz AND2.5mA Max.
5. Conducted EMI: Internal FilterCan Meet
A. CISPR 22 (EN55022)CLASS B
6. Product safety: the power supply is designed to meet the following safetystandards.
6.1 UL/CUL
7. Environment:
7.1 OperatingTemperature: 0℃ TO 40℃
7.2 Operating Relative Humidity: 5% TO 95%.
7.3 Storage Temperature: -40 TO + 70 ℃.
7.4 Storage Relative Humidity: 5% TO 95%.
7.5 Altitude: Operate Properly At Any AltitudeBetween 0 To 10,000 Feet. Storage: 50,000 Feet.
7.6 Non-operating shock:
Half sine shock
Duration 11ms by 50Gacceleration
Minimum 3 shocks on eachof six faces.
7.7Non-Operating Random Vibration:
0.015G^2/Hz 5 to 100Hz
-6dB/octave 100 to 137Hz
0.008G^2/Hz 137 to 350Hz
-6dB/octave 350 to 500Hz
0.0039^2/Hz 500Hz
2.09Grms
20 minutes/axis along all three axes.
8. Power Good Signal:
Note:
(1) T1: Power-on Time: T1 < 500ms
(2) T2: Rise time: T2 < 20ms
(3) T3: PWR_OK delay time: 100ms < T3 < 500ms
(4) T4: PWR_OK rise time: T4≦10ms
(5) T5: Power hold-up time:T5≧10ms, 230Vac/60Hz Full Load( load 4)
(6) T6: Power-down warning: T6≧1ms
9. M.T.B.F.:
100K Hours Min AtMax. Load 230Vac And 25℃ AmbientConditions.
10. Burn-in:
Unitshould be burn-in in 40+/-5°C, with 230Vac and 90% max load.
11. Case& Cable drawing(仅供参考，实物可能会稍有差异)
1. Input Characteristics:
1.1 InputVoltage Range: 200~240Vac.
1.2 Normal Voltage Range: 220/230Vac.
1.3 Input Frequency Range: 50-60 Hz.
1.4 Max Input AC current: 10A MAX. @ 230Vac.
1.5 Inrush Current: No hazards shall occur orcomponents damage.
1.6 Efficiency: ≥87%@230Vac 60Hz, load follow “2.2 DC output current table” Load 5.
1.7 Active PFC
2. Output Characteristics
2.1 Static Output Characteristics:
Output | Load Range | Regulation | Ripple & Noise | ||
Voltage | MIN. | MAX. | Peak | ||
+5V | 0 A | 12A | -5%/+5% | 150mV | |
+12V | 0A | 130A | -5%/+5% | 200 mV | |
-12V | 0A | 0.3A | -10%/+10% | 200 mV | |
+5VSB | 0 A | 2.5A | -5%/+5% | 150 mV | |
+3.3V | 0A | 12A | -5%/+5% | 150 mV | |
Max. Output Power: 1650W
2.2 DC output current:
Load | +5V(A) | +12V1(A) | +12V2(A) | +3.3V(A) | -12V(A) | +5VSB(A) |
1 | -- | 0.0 | ||||
2 | -- | 1.0 | ||||
3 | -- | 2.0 | ||||
128.0 | 12.0 | 0.30 | 2.0 | |||
5 | 6.0 | 64.0 | 6.0 | 0.15 | 1.0 | |
6 | 2.4 | 25.6 | 2.4 | 0.06 | 0.40 | |
7 | 1.0 | 120.0 | 12.0 | 0.3 | 1.0 | |
8 | 12.0 | 95.0 | 12.0 | 0.3 | 1.0 | |
9 | 0 | 120.0 | 1.4 | 0.3 | 1 | |
10 | 0.90 | 58.0 | 0 | 0.3 | 1 | |
11 | 11.80 | 125.0 | 1.0 | 0.3 | 2.5 | |
120.0 | 12.0 | 0.3 | 2.5 | |||
13 | 0 | 0 | 7.88 | 0 | 0 | |
14 | 0.2 | 0.05 | 0.3 | 0.0 | 0.0 | |
Note: 1. Noise Test: NoiseBandwidth is From 10Hz To 20 MHz.
2. Add 0.1uf Ceramic Capacitor /10uf Tantalum Capacitor At OutputConnector Terminals For Ripple & Noise Measurements.
3. Maximum Continuous DCOutput Power shall not exceed 1650W.
4. +3.3V and +5V total O/P power cannot exceed 100W.
The +12Vcombine is not exceed the 130A
5. Main O/P Shall Be Enabled By Pulled "Remote" Pin To TTLLow Level, And Disabled By
Pulled"Remote" Pin To TTL High Level.
6. When AC line power is applied, the +5VSB will present, and PS-ON signal is in a disable state, the +5VSb o/p shall be within regulation speclimit.
7. Cross regulations/Ripple&Noise test must with Fan cooling and following the defined loads
2.3Dynamic Output Characteristics
2.3.1Turn-On Delay Time: 500mS Max. At Any Condition. Ac Input With Respect To +5V.
2.3.2 Rise Time: any outputs rise time from 10% to 90% of normalvoltage should be less than 20 ms.
2.3.3 Hold-up time: 8ms min.@ 90% of full load 230Vac/60Hz respect to +5V o/p.
2.3.4 Overshoot: Any Overshoot At Turn On Or Turn Off Shall BeLess Than 10% Of The Normal Value.
2.3.5 The power supply should be able topower up and operate normally with the following capacitances simultaneously present onthe DC outputs. This capacitive loading should be used to check stability and should not be included fornoise testing the dynamic timing is 50Hz-10kHz
Note: When dynamic test, the 12V Min Load shall be 2A.
Output Capacitive Loads:
Output | Capacitive Loads(μF) | Max. Step size |
+12VDC | 10000 | 40% |
+5VDC | 6000 | 30% |
+3.3VDC | 6000 | 30% |
-12VDC | 350 | 0.1A |
+5VSB | 350 | 0.1A |
3. Protections:
3.1 OverVoltage Protection: +5V: 7.0V Maximum.
+12V: 16.5V Maximum
+3.3V: 4.3V Maximum
3.2 ShortCircuit Protection: The power supply shall shut down and latch off forshorting. +5V, +12V, -12V or +3.3v rails to com and each output rail andshorting +5vsb P/S can latch down or automatically Recovery When the faultcondition is removed.
3.4 NoLoad operation: No damage or hazardous condition will occur.
3.5 OCP: +12V without,+3.3V&+5Vwith
3.6 With FanSpeed Control Function:
4. Dielectric Withstand Voltage:
4.1 (a) Primary To Secondary: 2100Vac 1sec.
(b) Primary To F.G:2100Vac 1sec.
4.2 Insulation Resistance:Primary To Safety Ground: 500Vdc, 5 MΩ Min.
4.3 Leakage Current: Measured At 240Vac/50Hz AND2.5mA Max.
5. Conducted EMI: Internal FilterCan Meet
A. CISPR 22 (EN55022)CLASS B
6. Product safety: the power supply is designed to meet the following safetystandards.
6.1 UL/CUL
7. Environment:
7.1 OperatingTemperature: 0℃ TO 40℃
7.2 Operating Relative Humidity: 5% TO 95%.
7.3 Storage Temperature: -40 TO + 70 ℃.
7.4 Storage Relative Humidity: 5% TO 95%.
7.5 Altitude: Operate Properly At Any AltitudeBetween 0 To 10,000 Feet. Storage: 50,000 Feet.
7.6 Non-operating shock:
Half sine shock
Duration 11ms by 50Gacceleration
Minimum 3 shocks on eachof six faces.
7.7Non-Operating Random Vibration:
0.015G^2/Hz 5 to 100Hz
-6dB/octave 100 to 137Hz
0.008G^2/Hz 137 to 350Hz
-6dB/octave 350 to 500Hz
0.0039^2/Hz 500Hz
2.09Grms
20 minutes/axis along all three axes.
8. Power Good Signal:
Note:
(1) T1: Power-on Time: T1 < 500ms
(2) T2: Rise time: T2 < 20ms
(3) T3: PWR_OK delay time: 100ms < T3 < 500ms
(4) T4: PWR_OK rise time: T4≦10ms
(5) T5: Power hold-up time:T5≧10ms, 230Vac/60Hz Full Load( load 4)
(6) T6: Power-down warning: T6≧1ms
9. M.T.B.F.:
100K Hours Min AtMax. Load 230Vac And 25℃ AmbientConditions.
10. Burn-in:
Unitshould be burn-in in 40+/-5°C, with 230Vac and 90% max load.
11. Case& Cable drawing(仅供参考，实物可能会稍有差异)
Suitable for the power supply of a full series of graphics cards
