Product parameter
AC input voltage: AC100-240V 50/60Hz
Input current: 2.0A (maximum)
Output voltage: 36-60VD
Output current: 100-2330mA
Input surge current: 80A (maximum)
High voltage test: 3000Vac 10mA 3S
Output voltage ripple and noise: 500mVp-p max
Energy efficiency rating: VI
safety standard:
UL60950; FCC Part 15 Subpart B Class B
IEC/EN60335-1; IEC/EN61558-2-16
Safety rate:
Insulation resistance: 50MΩ (at 500VDC)
Overcurrent protection
Short circuit protection
Overvoltage protectio
Environmental requirements
Working temperature: -5°C-+40°C.
Storage temperature: -20°C-+60°C.
Working humidity: 30%-85%.
Storage humidity: 10%-95%.
Certification:
CB CE GS UL FCC CCC SAA RCM PSE KC BSMI VI
Electric bicycles (also called electric mopeds, smart bicycles) balance bikes, twist bikes, scooters, unicycles, drones, electric vehicles, etc.
